Wildcat SWZ-48V-LH

Despiece de Hydraulic System · SWZ-48V-LH

Despiece del Hydraulic System de una máquina Scag SWZ-48V-LH, con globos numerados
Pasa por encima de un recuadro para ver la pieza, su precio y su fila. Pincha para marcarla.
  • 1S482643No la vendemos
    Pump, BDP-10A-316 (LH)
  • 1S482644No la vendemos
    Pump, BDP-10A-419 (RH)
  • 2S482266-01No la vendemos
    Elbow, 90 Degree 9/16" O-Ring x 3/8" Hose
  • 3S48572-02No la vendemos
    Fitting, 1/2” JIC x 5/8" O-Ring
  • 4S48811No la vendemos
    Hose, 3/8" Pushlock (Specify length)
  • 5S482573No la vendemos
    Bushing
  • 6S482574No la vendemos
    Fitting
  • 7S482266-01No la vendemos
    Elbow, 90 Degree 9/16" O-Ring x 3/8" Hose
  • 8S48136-13No la vendemos
    Hose Clamp, .69" Dia.
  • 9S482548No la vendemos
    Hose Assembly
  • 10S04060-06No la vendemos
    Roll Pin
  • 11S48572-04No la vendemos
    Fitting, 1/2” JIC x 1/2” O-Ring
  • 12S48603-06No la vendemos
    O-Ring
  • 13S04001-20No la vendemos
    Bolt, Hex Head 3/8-16 x 1-1/2”
  • 14S04017-07No la vendemos
    Bolt, Hex Head 1/4-20 x 1-1/4”
  • 15S04030-02No la vendemos
    Lockwasher
  • 16S04021-09No la vendemos
    Nut, Elastic Stop 3/8-16
  • 17S422969No la vendemos
    Control Lever
  • 18S04001-08No la vendemos
    Bolt, Hex Head 5/16-18 x 3/4”
  • 19S04030-03No la vendemos
    Lockwasher, 5/16"
  • 20S04040-15No la vendemos
    Flatwasher, 5/16-.375 x .875 x .083
  • 21S481164No la vendemos
    Cap, Hydraulic Tank
  • 22S481507No la vendemos
    Insert, Filler Neck
  • 23S48829No la vendemos
    Control Block
  • 24S421203No la vendemos
    Clamp Plate
  • 25S461479No la vendemos
    Hydraulic Tank Assembly w/Fittings
  • 26S48603-06No la vendemos
    O-Ring, 9/16”
  • 27S482277No la vendemos
    Tee Fitting, O-Ring to Barb
  • 28S48136-13No la vendemos
    Clamp, .69" Max. / .25" Min. Dia.
  • 29S482571No la vendemos
    Bushing
  • 30S482572No la vendemos
    Elbow, 0.38" Hose
  • 31S48136-13No la vendemos
    Clamp
  • 32S482639No la vendemos
    Wheel Motor, Parker
  • 33S48603-02No la vendemos
    O-Ring, 3/4”
  • 34S482802No la vendemos
    Nipple, Oil Filter 1.0-12 UNF-2A x 1-1/4”
  • 35S04001-11No la vendemos
    Bolt, Hex Head 5/16-18 x 1-1/2" the individual engine manufacturer. 23
  • 36S48136-13No la vendemos
    Clamp, .69" Max. / .25" Min. Dia.
  • 37S482800-02No la vendemos
    Fitting, 9/16" O-Ring x 3/8" Hose
  • 38S04019-03No la vendemos
    Nut, Serr. Flange 5/16-18
  • 39S04041-07No la vendemos
    Flatwasher, 3/8-.391 x .938 x .105"
  • 40S48462-01No la vendemos
    Oil Filter
  • 41S482798No la vendemos
    Filter Head Assembly
  • 42S482800-01No la vendemos
    Fitting, 3/4" O-Ring x 3/8" Hose
  • 43S48604-03No la vendemos
    Plug, 9/16-18 O-Ring
  • 44S482557No la vendemos
    Hose, Filter Inlet
  • 45S482605No la vendemos
    Hose Assembly
  • 46S48811No la vendemos
    Hose, 3/8" Pushlock 15” Long
  • 47S04001-17
    $0.47
    BOLT, HEX HEAD 5/16-18 x 2"
  • 48S482708No la vendemos
    Cooler, Transmission
