Wildcat SWZ-48V

Despiece de 61V Cutter Deck · SWZ-48V

Despiece del 61V Cutter Deck de una máquina Scag SWZ-48V, con globos numerados
Pasa por encima de un recuadro para ver la pieza, su precio y su fila. Pincha para marcarla.
  • 1S461862
    $1,733.57
    CUTTER DECK W/ DECALS, SMWC-61V
  • 2S43687
    $7.63
    BOSS, SPRING ANCHOR-RH 61V
  • 3S424371
    $11.83
    ANCHOR BRKT, DECK SPRING - 61V
  • 4S481625-01
    $2.57
    WING NUT, 3/8-16
  • 5S481632
    $21.03
    Scag 481632 - ANTI-SCALP WHEEL
  • 6S04003-26
    $1.76
    Scag 04003-26 - CARRIAGE BOLT, 3/8-16 X 4.00
  • 7S422478
    $27.10
    ANTI-SCALP WHEEL BRACKET
  • 8S04017-27
    $1.21
    Scag 04017-27 - CPSCR,3/8-16X1"SERR FLG HH
  • 9S04043-06
    $1.72
    WASHER, 5/8 HARDENED
  • 10S04021-05
    $0.26
    Scag 04021-05 - LKNUT, 3/8-16 ELAS STOP
  • 11S461846
    $64.28
    DISCH CHUTE W/ TAG, 61V
  • 12S04001-11
    $0.62
    HHCS, 5/16-18 X 1.50 ZINC
  • 12S04001-12
    $0.46
    BOLT, HEX HEAD, 5/16-18 X 1.75
  • 13S04021-10
    $0.10
    Scag 04021-10 - 5/16-18 LOCKNUT ELASTIC TYPE
  • 14S04020-09
    $0.63
    HEX NUT, 5/8-11
  • 15S45944
    $21.04
    Scag 45944 - ROLLER SHAFT
  • 16S04001-41
    $11.79
    5/8-11X9-1/2 HH CP SCR GRD5
  • 17S48038No la vendemos
    Roller, Rear
  • 18S04001-154
    $2.54
    Scag 04001-154 - HH BOLT, 5/16-18 X 4.75 ZINC
  • 19S04063-08
    $1.08
    KEY BAR STOCK #C1018 1/4X1/4X2
  • 20S483246
    $49.53
    SPRING, LH DECK DRIVE - SMTC
  • 21S04043-04
    $0.70
    Scag 04043-04 - FLATWASHER, 3/8"
  • 22S04001-176
    $0.47
    Scag 04001-176 - HH BOLT, 5/16-18 X 1.75 GR 8 BLK
  • 23S04019-03
    $0.15
    Scag 04019-03 - NUT, 5/16-18 SERR FLG HH ZINC
  • 24S04001-172
    $0.18
    HH BOLT, 1/4-20 X 1.00 GR 8 BLK
  • 25S48100-15
    $4.69
    Scag 48100-15 - BUSHING, .376 I.D. OILITE
  • 26S04030-03
    $0.06
    Scag 04030-03 - 5/16LKWHR.586X.317X.078THK(A
  • 27S04040-15
    $0.07
    FLATWASHER, 5/16"
  • 28S483703
    $31.37
    DECK SPRING, SMTC
  • 29S04021-09
    $0.20
    3/8-16 ELASTIC HEX LKNUT
  • 30S461940No la vendemos
    Idler Arm Assembly, LH Drive
  • 31S461946
    $67.38
    IDLER ARM ASSY, SMTC
  • 32S483286
    $36.35
    Scag 483286 - PULLEY 6.33 OD - TAPER BORE
  • 33S04110-03
    $2.09
    U-NUT, 3/8-16
  • 34S461663
    $248.59
    SPINDLE ASSY
  • 35S43589
    $56.20
    Scag 43589 - SHAFT, CUTTER SPINDLE
  • 36S481024
    $4.36
    SEAL,2.00 OD X 1.50 BORE
  • 37S481022
    $57.56
    Scag 481022 Tapered Bearing Set
  • 38S48114-04
    $0.95
    Scag 48114-04 - GREASE FITTING 1/4-28 SELF-TAP
  • 39S48677
    $1.41
    Scag 48677 - RELIEF FITTING
  • 40S43644
    $56.87
    Scag 43644 - SPINDLE HOUSING
  • 41S43312
    $18.38
    Scag 43312 SW Outside Spacer
  • 42S43296
    $7.81
    SPACER, INSIDE
  • 43S481025
    $4.36
    SEAL,2.00 OD X 1.625 BORE
  • 44S43297
    $9.16
    Scag 43297 - SPINDLE BUSHING, BOTTOM
  • 45S481035
    $7.32
    NUT,1.06-18 THD
  • 46S43590
    $16.60
    Scag 43590 - SPACER, SPINDLE BOTTOM
  • 47S482879
    $24.89
    CUTTER BLADE, 21.0"
  • 48S483287
    $61.47
    Scag 483287 - PULLEY, 6.33 OD - DBL GROOVE
  • 49S424367
    $1.95
    DUST SHIELD
  • 50S483210No la vendemos
    Idler Pulley, 5” Dia. 5
  • 51S48181
    $25.17
    IDLER PULLEY
  • 52S424575
    $104.56
    BELT COVER, SMWC-61V
  • 53S48926
    $29.77
    TAPERED HUB
  • 54S483415No la vendemos
    Idler Pulley, 3-1/2” Dia.
  • 55S43689No la vendemos
    Pivot, Idler
  • 56S48224
    $12.51
    BALL BEARINGS-NEUTRAL RET.
  • 57S424209
    $68.07
    BAFFLE, TURBO - 61V
  • 58S451240
    $50.33
    ROD WLMT, PUSHARM
  • 59S461516
    $204.01
    PUSHARM ASSY
  • 60S04020-16
    $0.70
    Scag 04020-16 - NUT, 5/8-18 UNF ZINC
  • 61S04021-13
    $1.03
    5/8-11 ELASTIC STOP NUT ZINC
  • 62S48763
    $55.86
    Scag 48763 - ROD END, 5/8 MALE RH THD
  • 63S04001-79
    $4.69
    Scag 04001-79 - BOLT, HEX HEAD 5/8-11 X 4-1/2"
  • 64S48114-04
    $0.95
    Scag 48114-04 - GREASE FITTING 1/4-28 SELF-TAP
  • 65S483243
    $77.50
    Scag 483243 - BELT, DECK DRIVE - SMWC-61V
  • 66S04001-09
    $0.40
    HHCS, 5/16-18 X 1.00 ZINC
  • 67S483378
    $7.19
    SPRING, DISCHARGE CHUTE
  • 68S424841
    $115.38
    BAFFLE, FLG - 61V
  • 69S04003-23
    $1.31
    Scag 04003-23 - CARRIAGE BOLT, 3/8-16 X 1.0
  • 70S04041-07
    $0.47
    3/8 FWSHR 15/16X25/64X12GA
  • 71S04001-77
    $1.21
    Scag 04001-77 - BOLT, 3/8-16 X 3-1/2" HEX HEAD
  • 72S483157No la vendemos
    Belt, Deck Drive RH
  • 73S482295No la vendemos
    Wheel, Anti Scalp
  • 74S45944
    $21.04
    Scag 45944 - ROLLER SHAFT
  • 75S483167
    $16.89
    Scag 483167 - BOLT, DECK ADJUST
  • 76S04003-40
    $1.03
    CARR BOLT, 7/16-14 X 1.25
  • 77S461929
    $59.21
    Scag 461929 - LEVER ASSY, DECK LEVEL
  • 78S04001-136
    $0.46
    Scag 04001-136 - BOLT, HEX HEAD 3/8-16 X 1-1/2"
  • 79S04001-19
    $0.39
    Scag 04001-19 - BOLT, HEX HEAD, 3/8-16 X 1"
  • 80S04019-04
    $0.28
    Scag 04019-04 - NUT, 3/8-16 SERR FLG HH ZINC
  • 81S04030-04
    $0.06
    LOCKWASHE3/8"
  • 82S43689No la vendemos
    Pivot, Idler Short
  • 83S04003-12
    $0.36
    Scag 04003-12 - CARRIAGE BOLT, 5/16-18 X 3/4"
  • 84S483176
    $32.55
    Scag 483176 - PAD, DECK WEAR - 48A/52A/61A
  • 85S04040-04
    $0.06
    Scag 04040-04 - FLATWASHER, 5/16
  • 86S04021-04
    $0.26
    Scag 04021-04 - NUT, 5/16-18 CENTER LOCK
  • 87S04001-19
    $0.39
    Scag 04001-19 - BOLT, HEX HEAD, 3/8-16 X 1"
  • 88S04001-31
    $0.89
    Scag 04001-31 - BOLT, HEX HEAD, 3/8-16 X 2-1/2"
  • 89S04021-11
    $0.26
    Scag 04021-11 - HEX NUT, ELASTIC STOP, 7/16-14
  • 90S04040-11
    $0.40
    FLAT WASHER, 7/16"
  • 91S04001-46
    $0.81
    Scag 04001-46 - BOLT, HEX HEAD, 3/8-16 X 2-1/4"
  • 92S04001-54
    $0.96
    BOLT, HEX HEAD, 3/8-16X3"
  • 93S04021-09
    $0.20
    3/8-16 ELASTIC HEX LKNUT
  • 94S483287
    $61.47
    Scag 483287 - PULLEY, 6.33 OD - DBL GROOVE
