Cheetah SCZ-35CV

SCZ-35CV SCZ Engine & Attaching Parts Diagram

Exploded parts diagram of the SCZ Engine & Attaching Parts of a Scag SCZ-35CV, with numbered balloons
Hover a box for the part, its price and its row below. Click it to select.
  • 2S484581
    $57.72
    Scag 484581 - HOSE ASSY, ENG DRAIN - KA-FS/FX
  • 2S484706
    $38.97
    Scag 484706 - HOSE ASSY W/ COVER, SCZ-BV/CV
  • 2S484599
    $58.82
    Scag 484599 - HOSE ASSY, OIL DRAIN - SCZ-BV
  • 3S484593Not stocked
    Valve Assembly, Oil Drain
  • 4S484155
    $197.66
    Scag 484155 - MUFFLER, SCZ-FX
  • 4S485316
    $215.60
    MUFFLER, 824 KOHLER EFI
  • 4S484156
    $196.23
    Scag 484156 SCZ61V Muffler
  • 4S486108
    $298.41
    Scag 486108 - MUFFLER 37 BV-EFI
  • 5S04001-32
    $0.45
    BOLT, HEX HEAD, 3/8-16 X 1-1/4"
  • 6S04030-04
    $0.06
    LOCKWASHE3/8"
  • 7S425975Not stocked
    Bracket, Oil Drain Hose
  • 8S04010-30Not stocked
    Screw, #8-32 x 1/2”
  • 9S04021-17
    $0.20
    Scag 04021-17 - LKNUT, #8-32 ELASTIC STOP
  • 10S484617
    $2.85
    Scag 484617 - BUSHING, THICK PANEL SNAP
  • 11S484585
    $0.33
    CAP, VALVE
  • 12S48603-12
    $0.06
    O-RING, .50 X .0625
  • 13S484586
    $0.13
    SEAL, VALVE - RUBBER
